Geometry
A. Total Length:
B. Handlebar Height:
C. Handlebar Length:
D: Wheelbase:
E. Wheel Diameter:
F. Minimum Seat Height:
G: Maximum Seat Height:
H. Chain Stay Length:
I. Frame Stack: 32 in
J. Top Tube Length:
L. Head Tube Length:
N. Standover Height:
Specifications
Range: ~ 60 - 80 Miles
Battery: 48V 20Ah Samsung/LG Lithium Battery
Motor: 750W Brushless Geared Hub Motor
Display: LCD Display with USB Charging
Total Payload Capacity:
Recommended Rider Heights: ~5'3" - 6'5"
Weight (with battery):
Charger: US Standard 3.0A Smart Charger
Pedal Assist: 0-5 Level Pedal Assist (Customizable up to 9 levels)
Controller: 48V / 22A
Components
Throttle: Thumb Throttle
Sensors: Torque Sensor | Speed Sensor | Brake Sensor
Front Fork: DASH-AIR-20 Inverted Fork 120mm lockout & rebound adjustable
Rear Shock : DNM A0-38RC rear shock 190*45mm
Drivetrain: Shimano Acera M3020 8-Speed
Brakes: Front: Tektro HD-E350 hydraulic brakes with Tektro 203mm Rotor, Rear: Tektro HD-E350 hydraulic brakes with Tektro 203mm Roto
Chain: KMC Z8.3 EPT 122L
Tires: 26" x 4.5" Kenda X Himiway
Seat Post: SP-2003 30.9*350mm
Stem: XF-827 alloy Ext:50mm
Cassette: Shimano 8-Speed CS-HG41.8 11-34T
Bike Frame: 6061 Aluminum Frame
Pedals: Alloy with reflectors
Headlight: Integrated 48V LED Light
Taillight: Battery Powered Bike Light
Cranks: Crank arm: EB-01-242A-S1 170mm | Chain ring: 40T 104BCD narrow wide chainring
Highlights
-
Upgraded 1000W Motor
1000W Upgraded Brushless Geared Hub Motor Use the latest updated inner ring specialized in high temperature resistance and better heat dissipation, which can reduce the motor magnets’ attenuation speed to guarantee a longer life expectancy. The 1000W brushless gear hub motor can help you conquer even the most rugged terrain easily.
FOC (Field Oriented Control)
You can think of the FOC as the brain controlling the motor in real-time. It recognizes your riding conditions and instantly calls on the motor for optimal performance. The FOC measures scooter diagnostics, which you as a driver cannot see, and then decides how to respond to your driving inputs.
-
Four Bar Linkage Suspension
It's the first e-bike in the U.S. market with four-bar linkage suspension technology, complemented with 4.5" Himiway by Kenda Fat Tires. These aid in absorbing both rear-upward force and vibrations, allowing you to ride safely over rutted trails, deep snow and soft sand with greater ease.
-
960Wh High Performance Lithium-Ion Battery
New top of the line Samsung/LG battery technology combined with a 5,000mAh single cell capacity in smaller size for larger diversity. Compared with other 3500mAh cells made from nickel, cobalat and manganese, this 960Wh (20Ah) battery vastly imporoves the range, stability and safety of Himiway bikes. A single charge can last up to 60 miles on pure electric power and 8+ miles with pedal assist. The battery should maintain 80% capacity after 1,000 charges.
- Battery Weight: 8.8 pounds
- Range can be affected by several factors such as rider/payload weight, incline, pedal assist levels, weather, etc.
-
Tektro Hydraulic Brakes with 203mm/180mm Rotors
Powerful hydraulic brakes from Tektro for consistent braking performance. The D7 features a larger 203mm front rotor with 180mm rear rotor.
-
Thumb Throttle
The thumb throttle is intended to give the rider better control of the bike, maintaining balance of the bike without accidental bumps of a twist throttle.
-
Torque Sensor
The intuitive torque sensor seamlessly amplifies your pedaling efforts, providing a more natural riding experience while conserving battery life and extendning riding range.
