Himiway D7 Pro Upgraded Full Suspension Mid Drive Fat Tire Electric Mountain Bike
Himiway D7 Pro Upgraded Full Suspension Mid Drive Fat Tire Electric Mountain Bike
The all-new, upgraded Himiway D7 Pro will knock your socks off. With hundreds of dollars of upgrades over the original Cobra Pro, the D7 Pro is in a class of its own. It is equipped with the powerful Bafang M620 1000W mid-drive motor, which is considered one of the leading manufacturers of electronic drive systems. 1300W of peak power will help you conquer the roughest terrain. An upgraded four-bar link suspension system with a four-sided polygon design promotes superior vibration absorption. With 220mm of front travel, the Himiway D7 Pro keeps you safe and give you the best riding experience on your next off-road adventure. It also features an upgraded 10-speed drivetrain with a 11-48T cassette for easy climbing, improved 4-piston hydraulic brakes for safer handling and a dropper post for downhill control.
Share
Geometry
A. Total Length: 78.7 in
B. Handlebar Height: 42.7 in
C. Handlebar Length: 30.7 in
D. Wheelbase: 52.6 in
E. Wheel Diameter: 28.7 in
F. Minimum Seat Height: 20.9 in
G. Maximum Seat Height: 30.4 in
H. Chain Stay Length: 20 in
I. Frame Stack: 24.6 in
J. Frame Reach: 18.6 in
K. Effective Top Tube Length: 24.4 in
L. Head Tube Length: 5.5 in
M. Head Angle: 64°
N. Standover Height: 30.7 in
Collapsible content
Specifications
Range: 60 - 80 Miles*
Battery: LG 48V 20Ah
Motor: Bafang M620 1000W mid-drive motor
Display: Bafang DP C18 LCD display
Total Payload Capacity: 400 lb
Recommended Rider Heights: 5'3" - 6'5"
Weight (with battery): 88.6 lb
Charger: US standard 3.0 A smart charger
Pedal Assist: 0-5, with Eco and Sport Modes
Controller: 48V/30A
Components
Throttle: Thumb throttle
Sensor: Torque sensor丨Shifting sensor丨Speed sensor丨Brake sensor
Front Fork: KKE R150S coil spring fork compression/Rebound adjustable 220mm travel 15*150mm thru axle
Rear Shock : ROCKSHOX deluxe select+ 190*45mm
Drivetrain: Shimano Cues U6000 10 speed
Brakes: Front: Tektro Dorado HD-E730 4-piston hydraulic brake w/ 203mm rotor | Rear: Tektro Dorado HD-E730 4-piston hydraulic brake w/ 180mm rotor
Chain: KMC E-Glide 130L
Tires: CST Roly Poly 26" x 4.8"
Seat Post: EXA Speed-up Dropper Post 30.9*500mm 150mm travel
Stem: 3D forged alloy Ext:50mm
Cassette: Shimano Cues CS-LG400-10 11-48T
Bike Frame: 6061 Aluminum
Pedals: Wellgo B087B Alloy
Headlight: 48V LED Integrated headlight
Taillight: Battery LED Light
Cranks: Crank arm: M620 (Fat) 170mm | Chain ring: 38T 104BCD narrow wide chainring
Highlights
-
Bafang M620 1000W Geared Mid Drive Motor
The torque-sensing mid-motor provides massive amounts of torque when powering up steep hills or accelerating quickly from a dead stop. With 1300W of peak motor power, you can easily conquer the most rugged terrains.
- 160 Nm max torque
- 1000W geared mid motor
-
Four Bar Linkage Suspension
It's the first e-bike in the U.S. market with four-bar linkage suspension technology, complemented with 4.8" CST Roly Poly Fat Tires. These aid in absorbing both rear-upward force and vibrations, allowing you to ride safely over rutted trails, deep snow and soft sand with greater ease.
-
960Wh High Performance Lithium-Ion Battery
New top of the line Samsung/LG battery technology combined with a 5,000mAh single cell capacity in smaller size for larger diversity. Compared with other 3500mAh cells made from nickel, cobalat and manganese, this 960Wh (20Ah) battery vastly imporoves the range, stability and safety of Himiway bikes. A single charge can last up to 60 miles on pure electric power and 8+ miles with pedal assist. The battery should maintain 80% capacity after 1,000 charges.
- Battery Weight: 8.8 pounds
- Range can be affected by several factors such as rider/payload weight, incline, pedal assist levels, weather, etc.
-
Tektro Dorado 4-Piston Hydraulic Brakes
Hydraulic brakes provide superior braking performance and durability. Featuring a 203mm front rotor and 180mm rear rotor, your brake performance is consistent, powerful and reliable.
-
10 Speed Shimano Deore Drivetrain
The Shimano Cues 10-speed ebike specific gear shift system offers you more choice while riding in a variety of conditions. Along with the pedal-assist system, you can find the speed that suits your journey. Using this system accurately can increase the range of a single charge by up to 15%.
-
Bafang Full Color LCD Display
Easily see your speed, distance traveled, trip time, battery level, and more on the backlit Smart LCD display.
- USB Charging
- Security Code
- State of Riding
- Fault Warning
- Cycling Data
- Function Set
-
Thumb Throttle
The thumb throttle is intended to give the rider better control of the bike, maintaining balance of the bike without accidental bumps of a twist throttle.
-
220mm Travel Dual Crown Fork
With 220mm of available compression, it is the perfect fit for your chosen terrain. This durable dual crown coil fork has adjustments for the spring's stiffness along with a lock-out lever. Double-shoulder inverted oil spring fork has compression and rebound adjustment, stable performance and 220mm of travel.
-
CST Roly Poly 26" x 4.8" Ultra Fat Tires
The 26 X4.8 CST all-terrain fat tires are the biggest fat tires in the U.S. e-bike market, providing upgraded grip and traction on rugged roads. Even in the most challenging terrains and weather conditions, these fat tires guarantee your safety and offer you an smooth and easy riding experience.
